PRODUCT INFORMATION
Codeline 40S is membrane housing series of 4” diameter with side entry design. This is used for commercial, municipal and industrial RO applications. Vessel models are available in operating pressure of 300 PSI, 450 PSI and 600 PSI with multiport connectivity. These are made up of epoxy/ glass composite to meet the demands of long term and continuous use in RO processes. Codeline 40S vessels can accommodate any standard 4” membrane element. The 40S series also comes with an optional sanitary connection.
Code compliant head
High gloss exterior paint
Multiporting
One piece engg thermoplastic head
- med1
- med2
- med3
- med4
FEATURES
- Mirror Finish ID for easy and quick loading and unloading of membranes
- Multi-porting option for connecting vessels to each other
- Quick lock head retention system for quick access to membranes
- Exteriors coated with high-gloss polyurethane paint for UV resistance
- Captured head seal prevents roll during head assembly fitting
- Various options available in ASME certified and CE marked models
- Non-coded vessel models are available up to 600 PSI
- CodeLine 40S non-coded is CE and NSF certified
- CodeLine 40S coded is ASME, CE and NSF certified
-
UNIQUE BENEFITS
-
THE 40S MEMBRANE HOUSING HAS 5 UNIQUE BENEFITS
- End plug assembly: Single-piece head assembly for non coded models with high-grade thermoplastic material reduces the number of spares.-
- Improved head sealing: Integration into the end plug, head/sealing plate provides better sealing and avoids head seal roll, eliminating head leaks
- Integrally wound locking groove: enhanced end-margin strength for better performance
- Membrane elements: Housing can accommodate a maximum of six membrane elements
- Ultrapure/sanitary applications: the coded models in the 40S series can optionally accommodate a specially designed sanitary connection
- End plug assembly: Single-piece head assembly for non coded models with high-grade thermoplastic material reduces the number of spares.-
-
PARTS OVERVIEW CODED
-
EXPLODED VIEW
The membrane housings of the coded 40S series are shown in the exploded views below. The parts tables contains an explanation of the numbers. Clicking the picture opens a PDF file containing both the exploded view and the parts table.
PARTS TABLE
-
PARTS OVERVIEW NON-CODED
-
EXPLODED VIEW
The membrane housings of the non-coded 40S series are shown in the exploded views below. The parts tables contains an explanation of the numbers. Clicking the picture opens a PDF file containing both the exploded view and the parts table.
PARTS TABLE
-
SPECIFICATIONS
-
SPECIFICATIONS - CODED MODELS
CODELINE 40S30 CODELINE 40S45 CODELINE 40S60 Drawing no. 99311 99315 99313 Design/ Max. operating pressure 300 PSI/20 Bar 450 PSI/31 Bar 600 PSI/41 Bar Max. operating temperature 120°F/ 49° 120°F/ 49° 120°F/ 49° Qualification pressure 1800 PSI/124 Bar 2700 PSI/186 Bar 3600 PSI/248 Bar Element length 1-6 1-6 1-6 Download adapter list DOWNLOAD DOWNLOAD DOWNLOAD Download datasheet DOWNLOAD DOWNLOAD DOWNLOAD Download drawing DOWNLOAD DOWNLOAD DOWNLOAD Quality: read more about our quality certificates.
Multiporting: learn more about multiporting with Codeline pressure vessels
Older products: click here for more information about older Codeline products.
User Guides: click here for all the Codeline User Guides.
SPECIFICATIONS - NON CODED MODELS
CODELINE 40S30 CODELINE 40S45 CODELINE 40S60 Drawing no. 99312 99316 99314 Design/ Max. operating pressure 300 PSI/20 Bar 450 PSI/31 Bar 600 PSI/41 Bar Max. operating temperature 120°F/ 49°C 120°F/ 49°C 120°F/ 49°C Qualifaction pressure 1800 PSI/124 Bar 2700 PSI/186 Bar 3600 PSI/248 Bar Element length 1-6 1-6 1-6 Download adapter list DOWNLOAD DOWNLOAD DOWNLOAD Download datasheet DOWNLOAD DOWNLOAD DOWNLOAD Download drawing DOWNLOAD DOWNLOAD DOWNLOAD Quality: read more about our quality certificates.
Multiporting: learn more about multiporting with Codeline pressure vessels
Older products: click here for more information about older Codeline products.
User Guides: click here for all the Codeline User Guides.
